| Place of Origin: | Guangdong, China |
| Brand Name: | Richmor |
| Model Number: | RCM-MDR9108 |
4g wifi mobile car nvr 8 channel mnvr with gps 4g and wifi
| PRODUCT DESCRIPTION | |
| Resolution | 8CH 1080P IPC Full real-time recording |
| Module | G-Sensor built in, GPS /3G/4G /WIFI (5.8G or 2.4G )Optional |
| Storage | Support 1*2TB HDD+1*128 SD card |
| Alarm I/O | 8CH Alarm input,2CH Alarm output |
| ACC Delay | 10 seconds delay pow-off for data protection |
| Voltage | 8V-36V Wide range voltage power supply |
Detailed specification was listed as follows for checking, please contact us we'll do our best to cooperate.
|
Item |
Parameter |
||
|
OS |
Linux |
||
|
Language |
Chinese/English/Others(can be customized) |
||
|
Video Compression |
H.264 |
||
|
Operation Interface |
OSD menu |
||
|
Video Input |
Support 8 CH Full real-time AHD 1080P | ||
|
Video Record System
|
Video Output |
1 CH composite video output, 1CH VGA output |
|
|
Display |
1/2/4/8 CH full screen |
||
|
Signal system |
PAL/NTSC (PAL @100Frame, NTSC@120 Frame |
||
|
Resolution |
Support 8 CH Full real-time AHD 1080P |
||
|
Record Format |
Synchronized A/V recording | ||
|
Audio |
Audio Input |
8 CH |
|
| Audio Output |
1 CH |
||
| Compression |
G.711 |
||
| Alarm |
Input |
8CH | |
| Output | 2CH | ||
| Storage |
2.5’’ 2TB HDD + 128GB SD Card |
||
|
Communication Port |
2CH RS232 / 2CH RS485 |
||
|
G-sensor |
Built in, support 3 Axis Motion Detection with user set ranges , for X,Y and Z coordinates |
||
|
Wireless communications |
GPS /3G /4G /WIFI optional |
||
|
GPS |
GPS /Glonass |
||
|
Video Playback |
Video Search |
Search video by Record Time/ Type etc |
|
|
Playback |
A/V,GPS,Map view,Speed,G-sensor,video files available for playback on PC. |
||
|
CMS |
Wireless(require Wi-Fi or cellular), real-time monitoring .GPS and alarm etc |
||
|
Operating Voltage |
Voltage Input |
8V ~ 36V DC |
|
|
Voltage Output |
12V @2.5A |
5V @2.5A |
|
|
Power -off Protection |
All video information can be saved automatically when the power cut off, and make sure that all the files can not be damaged |
||
|
UPS |
External UPS battery optional, support 24 hours monitoring |
||
|
Other |
Operation Temperature |
-20℃ ~ + 70℃ |
|
|
Humidity |
20% ~ 80% | ||
|
Dimension |
187*188*67mm |
||
| Weight | 1.8KG | ||
| RCM-MNVR9108 Accessories | |
| Standard | |
| Key*1 | CD*1 |
| Remote controller*1 | 6PIN Power cable*1 |
| NVR output*1 | NVR16PIN alarm cable*1 |
| NVR24PIN alarm cable*1 | NVR VGA cable*1 |
| USB cable*1 | NVR input cable*8 |
| Optional | |
| 4G Antenna | GPS Antenna |
| WIFI Antenna | |
