Product Details
1.Integrated WIFI module, support AP and STATION mode. In AP mode, you can use the operation and maintenance APP connection for debugging and maintenance.
2.8V~36V adaptive wide voltage input, ultra-low power consumption. Supports reverse connection protection and overload protection. Supports 12V power output.
3.Professional and reliable file system to ensure the accuracy and stability of video data and storage media.
4.TF card storage is supported. A single card supports a maximum of 512 GB. Support for hot swap.
5.4CH alarm input, 1CH RS232. Support extended serial port, external acousto-optic alarm or LED light screen.
6.Integrated WIFI module, support AP and STATION mode. The mobile APP can be used for quick setting and operation and maintenance .
7.Support TTS voice function, can achieve English and Chinese TTS scheduling broadcast.
8.Support alarm button emergency alarm trigger snap pictures
9.Delay shutdown function, delay time can be set.
10.It can realize ultra-low power sleep and continue to report the location. Keep position updated.
11.The professional platform software can realize the remote monitoring and management function of computer and mobile phone.
12.Optional side-mounted camera can realize DMS function or in-car monitoring function. The Angle of the side-mounted camera can be adjusted horizontally to support movement.
13.Ultra-low power consumption design, less heat, fast start!
Parameter
| Operating System |
Linux |
| Network Type |
4G TDD-LTE, FDD-LTE/3G |
| Memory |
2GB |
| Integrated camera |
HD 720P camera (DSM is infrared black and white camera) |
| Other cameras (external) |
HD 720P camera |
| GPS |
Dual-mode positioning, support GPS+ Beidou,
Positioning accuracy ≤10m(95% probability)
Positioning time: hot starting ≤5s, cold starting ≤45s
|
| WiFi(optional) |
2.4G；IEEE 802.11b/g/n |
| Speakers |
8 euro 1W, voice cavity |
| MIC |
Single wheat supports echo and noise cancellation |
| G-sensor |
3 axle Gravity acceleration sensor |
| Loop noise |
Compatible with hardware loop noise elimination |
| Module band |
UMTS:850/900/1900/2100MHz
HSUPA/HSDPA:850/1900/2100MHz
GSM/GPRS/EDGE:850/900/1800/1900MHz
|
| Module type |
Support built-in 3G/4G wireless transmission function
TDD-LTE, FDD-LTE
|
| Support agreement |
Support UDP,TCP/IP protocol |
| Voice serve |
HR/FR/EFR and AMR |
| HR/FR/EFR and AMR |
SMS |
Different from other dashcam-BK6MJ main features are.
1.It is very flexible in design and can connect 1ch.2ch.3ch.4ch and MAX 5 channels. Have different installation types suitable for different vehicle models. Can external 2 or 3 cameras, camera angle can be adjusted and locked.
2. With AI function, built-in ADAS road facing camera,DSM driver state monitor optional. The ADAS camera completely fits the windshield and will not be affected by reflections.
3.All in one, built-in speakers, microphones, tow-way talker, recorders and other functions. With 1080P AHD image quality, adopting H.265 video compression. Single SD card 4 ch 200 hours 512GB. All data is locked very safety and can also be opened for download.
4. Using ABS+PC material, the core part adopts heat dissipation treatment. The operating temperature can reach -30℃~80℃ 5. The cable is very mini and easy to install. The detachable installation method is convenient for installation and maintenance.
